Bluetooth Pulse oximeter

Model: WH50FW
cheap luxury replica watches uk

Major Features

■Small in volume、light in weight and convenient in carrying

■Operation of the product is simple ,low power consumption

■SpO2 value display

■Pulse rate value display, bar graph display

■Pulse waveform display

■The display mode can be changed

■Screen brightness can be changed

■A pulse rate sound indication

■With measured data overruns limits and low-voltage alarm function，the

upper/down alarm range is adjustable

■With clock function replica watches shop

■Battery capacity indication

■Low-voltage indication: low-voltage indicator appears before working abnormally

which is due to low-voltage，and with alarm function

■With SpO2 value and pulse rate value of storage, the storage data can be uploaded

to computers

■Real-time data can be transmitted to computers

■Connected with an external oximeter probe

■Wireless communication function(Bluetooth Function)（WH50FW）

Main performance

Display Mode: 65K Color OLED display

Screen Resolution: 128*96

SpO2 Measuring Range: 0%～100%, (the resolution is 1%).

Accuracy: 70%～100%: ±2% ,Below 70% unspecified.

PR Measuring Range: 30bpm～250bpm, (the resolution is 1bpm)

Accuracy: ±2bpm or ±2% (select larger)

Measurement Performance in Weak Filling Condition:

SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2

error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).

Resistance to Surrounding Light: The deviation between the value measured in the

condition of man-made light or indoor natural light and that of darkroom is less than

±1%.

Power Consumption: less than 100mA

Voltage: DC 3.6V～4.2V

Power Supply: Voltage 3.7 rechargeable lithium battery × 1

Battery Working Hour: 20 hours

Battery working life: Charge and discharge no less than 500 times.

Safety Type: Interior Battery，BF Type

Accessories

Sell in standard:

■A user manual

■A USB line

■A wristband

■A disk (PC software)

■An adult-oximeter probe

■A power adapter (GTM41076-0605;CMS0105)

Sell in addition:

■Other oximeter probe(Refer to probe application instruction for details and notice

renewal)

Physical Identity
top replica watches uk

Dimension: 61(L) × 56(W) × 24 (H) mm

Weight: About 50g (with the lithium battery*1)

Qualification

WH50F passed FDA and CE
